DIN 46235 Copper Compression Cable Lugs
Our factory manufactures DIN 46235 Copper Compression Cable Lugs for cable termination using the DIN 46235 series form and its listed model references. This family contains 18 listed options using AWG references. Compare the model, conductor and construction fields below, then send the connection drawing, quantity, packaging and destination requirements for factory matching and quotation.
描述
Product overview
The DIN 46235 Copper Compression Cable Lugs series is supplied for cable termination using the DIN 46235 series form and its listed model references. A compression lug combines a conductor barrel with a mounting palm or tongue. The electrical and mechanical joint is formed by controlled deformation of the barrel with a matched terminal, conductor, tool, die, profile, and crimp sequence.
DIN 46235 is part of this series identity and model system. When a project requires formal compliance, request the applicable declaration, test record, and exact model scope instead of treating the family name as certification evidence.
Product features and selection points
- Product use: Cable termination using the DIN 46235 series form and its listed model references.
- Series coverage: 18 listed size and configuration entries with AWG references.
- Terminal material: Copper.
- Selection basis: Choose the conductor reference first, then check barrel fit, mounting-hole pattern, palm geometry, angle, and equipment drawing. A matching wire gauge alone does not prove that the cable construction or outside diameter will fit the barrel.
Key product information
Available models and parameters
Conductor size entries include 1/0 AWG, 1000/1250 AWG, 12-10 AWG, 1500/1750 AWG, 2 AWG, 2/0 AWG, plus 12 additional size entries in the table. Model references include DIN50, DIN625, DIN6, DIN800, DIN35, DIN70, plus 12 additional model references.
The table below lists model / item, conductor size reference, and terminal material for this series. If your project needs a dimension, stud size, hole spacing, tool, die, torque, rating, or compliance document that is not listed, include the exact model or drawing with your RFQ.
| Model / item | Conductor size reference | Terminal material |
|---|---|---|
| DIN50 | 1/0 AWG | Copper |
| DIN625 | 1000/1250 AWG | Copper |
| DIN6 | 12-10 AWG | Copper |
| DIN800 | 1500/1750 AWG | Copper |
| DIN35 | 2 AWG | Copper |
| DIN70 | 2/0 AWG | Copper |
| DIN1000 | 2000 AWG | Copper |
| DIN150 | 250/300 AWG | Copper |
| DIN95 | 3/0 AWG | Copper |
| DIN185 | 300/350 AWG | Copper |
| DIN25 | 4 AWG | Copper |
| DIN120 | 4/0 AWG | Copper |
| DIN240 | 400/500 AWG | Copper |
| DIN300 | 500 AWG | Copper |
| DIN16 | 6 AWG | Copper |
| DIN400 | 600/750 AWG | Copper |
| DIN10 | 8 AWG | Copper |
| DIN500 | 800/1000 AWG | Copper |
Selection note: A listed size or configuration is one input, not a complete fit check. Confirm conductor construction, product geometry, mating or mounting details, and the installation method before approval.
How to specify this product
Choose the conductor reference first, then check barrel fit, mounting-hole pattern, palm geometry, angle, and equipment drawing. A matching wire gauge alone does not prove that the cable construction or outside diameter will fit the barrel.
For quotation matching, send the conductor size and construction, the target connection or mating interface, a drawing or model reference, required quantity, packaging instructions, destination market, and any document or test requirement. We will return the available option for your review before order confirmation.
Factory quotation and OEM/ODM support
Voltix manufactures electrical connection products in our own 1,000+ m2 factory, supported by 12+ production operators, more than five years of manufacturing experience, and a five-person export team for OEM/ODM, sampling, documentation and international project communication.
Tell us whether you need a standard catalogue item, packaging changes, private labeling, sample approval, or drawing-based OEM/ODM work. Final dimensions, materials, compatibility, tooling, ratings, standards, certifications, MOQ, and lead time are confirmed against the selected model and quotation documents.
