PNT Non-Insulated Parallel Splice Terminals
Our factory manufactures non-insulated parallel splice terminals in the PNT Non-Insulated Parallel Splice Terminals series for joining conductor ends in the parallel-splice arrangement represented by the PNT series. This family contains 13 listed options using AWG references. Compare the model, conductor and construction fields below, then send the connection drawing, quantity, packaging and destination requirements for factory matching and quotation.
描述
Product overview
The non-insulated parallel splice terminals in the PNT Non-Insulated Parallel Splice Terminals series are supplied for joining conductor ends in the parallel-splice arrangement represented by the PNT series. A parallel splice arranges the conductor connection differently from an end-to-end butt splice. That structural difference affects how the conductors enter the connector and how the joint is prepared.
PNT is a non-insulated parallel-splice family. Its conductor-entry arrangement differs from an end-to-end butt splice, so the buyer should provide the intended wire layout as well as both conductor references.
Product features and selection points
- Product use: Joining conductor ends in the parallel-splice arrangement represented by the PNT series.
- Series coverage: 13 listed size and configuration entries with AWG references.
- Selection basis: Confirm the intended conductor arrangement, conductor size and construction, insertion method, and matched crimp tooling. Do not substitute a butt-splice procedure without the exact model instructions.
Key product information
Available models and parameters
Conductor size entries include 1/0 AWG, 12-10 AWG, 14-12 AWG, 16-14 AWG, 2 AWG, 2/0 AWG, plus 7 additional size entries in the table. Model references include PNT60, PNT5, PNT3, PNT2, PNT38, PNT70, plus 7 additional model references.
The table below lists model / item and conductor size reference for this series. If your project needs a dimension, stud size, hole spacing, tool, die, torque, rating, or compliance document that is not listed, include the exact model or drawing with your RFQ.
| Model / item | Conductor size reference |
|---|---|
| PNT60 | 1/0 AWG |
| PNT5 | 12-10 AWG |
| PNT3 | 14-12 AWG |
| PNT2 | 16-14 AWG |
| PNT38 | 2 AWG |
| PNT70 | 2/0 AWG |
| PNT1 | 22-16 AWG |
| PNT0.5 | 26-22 AWG |
| PNT80 | 3/0 AWG |
| PNT22 | 4 AWG |
| PNT100 | 4/0 AWG |
| PNT14 | 6 AWG |
| PNT8 | 8 AWG |
Selection note: A listed size or configuration is one input, not a complete fit check. Confirm conductor construction, product geometry, mating or mounting details, and the installation method before approval.
How to specify this product
Confirm the intended conductor arrangement, conductor size and construction, insertion method, and matched crimp tooling. Do not substitute a butt-splice procedure without the exact model instructions.
For quotation matching, send the conductor size and construction, the target connection or mating interface, a drawing or model reference, required quantity, packaging instructions, destination market, and any document or test requirement. We will return the available option for your review before order confirmation.
Factory quotation and OEM/ODM support
Voltix manufactures electrical connection products in our own 1,000+ m2 factory, supported by 12+ production operators, more than five years of manufacturing experience, and a five-person export team for OEM/ODM, sampling, documentation and international project communication.
Tell us whether you need a standard catalogue item, packaging changes, private labeling, sample approval, or drawing-based OEM/ODM work. Final dimensions, materials, compatibility, tooling, ratings, standards, certifications, MOQ, and lead time are confirmed against the selected model and quotation documents.
